Dahua X24A5L 32-Channel Penta-brid HD-CVI DVR Digital Video Recorder

SKU : X24A5L Categories ,

32-Channel Penta-brid HD-CVI DVR Digital Video Recorder

HDCVI technology seamlessly integrates traditional analog surveillance systems with upgraded, high-quality HD video, making it the best choice to protect security investments. The plug and play approach enables full HD video surveillance without the hassles of configuring a network.

The digital video recorder offers Penta-brid access technology to seamlessly record video from HDCVI, AHD, TVI, CVBS, and IP sources simultaneously. The Penta-brid recorder offers advanced options such as built-in motion detection algorithms, and customized recording modes.

The X24A5L series supports 32 camera inputs, 16 of which can be HDCVI, AHD, TVI, or CVBS cameras and the remainder IP cameras. In addition, the recorder supports a maximum of 16 local live-view channels and 16 playback channels.

Dahua X24A5L 32-Channel Penta-brid HD-CVI DVR Digital Video Recorder



  • 240fps/4M-N
  • 32 channel Analog/CVI Inputs
  • 16 channel IP Video Inputs
  • 1.5U
  • 4/1 Audio
  • 16/6 Alarm
  • DC12V/5A
  • 480fps/1080P, 960fps/720P
  • Embedded Processor
  • Smart H.265+ and Smart H.264+ Dual Codec
  • Maximum 96 Mbps Incoming Bandwidth
  • Built-in Smart Search
  • 32 HDCVI/AHD/TVI/CVBS Channels
  • Dual-stream Recording
  • Intelligent Video System
  • 4 SATA HDD up to 32TB
  • 16 + 8 IP Channels, up to 6 MP per Channel
Weight 6.5 lbs
Dimensions 44 × 41.7 × 7.6 cm

Max. Storage Capacity


, ,



32 CH

IP Video Input

16 CH

Bandwidth In/out
