| Specifications |
| Camera |
| Image Sensor |
1/3 ” Progressive Scan CMOS |
| Min. Illumination |
0.01Lux @ (F1.2, AGC ON), 0 .018Lux @ (F1.6, AGC ON) |
| Shutter Speed |
1/3 s to 1/10,000 s |
| Lens |
2.8mm to 12mm Horizontal view: 98° to 28°,Vertical view: 51° to 16°,Diagonal view: 115° to 32° |
| Lens Mount |
Φ14 |
| Day & Night |
IR cut filter |
| DNR |
3D DNR |
| Wide Dynamic Range |
True WDR 120dB |
| Angle Adjustment |
Pan: 0° to 355°, tilt: 0°to 70°, rotation: 0° to 360° |
| Compression Standard |
| Video Compression |
Main stream: H.2 65/H.264 Sub stream: H.265/H.2 64/MJPEG |
| H.264 / H.264+Type |
Baseline Profile/ Main Profile/ High Profile |
| H.265 / H.265+ Type |
Main Profile / Main Stream Support |
| Video Bit Rate |
32 Kbps ~ 8 Mbps |
| Image |
| Max. Resolution |
2560 × 1440 |
| Main Stream |
50Hz: 20fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60Hz: 20fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Sub Stream |
50Hz: 20fps (704 × 576, 352 × 288, 640 × 480, 320 × 240) 60Hz: 20fps (704 × 480, 352 × 240, 640 × 480, 320 × 240) |
| Image Enhancement |
BLC/ 3D DNR |
| Image Settings |
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
| Network |
| Network Storage |
NAS (NFS,SMB/CIFS) |
| Alarm Trigger |
Motion detection, video tampering alarm, illegal login |
| Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| General |
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
| Standard |
ONVIF(PROFILE S,PROFILE G),ISAPI |
| Interface |
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| Reset |
Built-in microSD/SDHC/SDXC slot, up to 128 GB |
| General |
Working Temperature
/Humidity |
-22 °F ~+122 °F(-30 °C ~ +50 °C) Humidity 95% or less (non-condensing) |
| Power Supply |
DC 12V ± 25% |
| Power Consumption |
Max. 5W 12 VDC ± 25%, |
| IR Range |
Up to 100ft |
| Weather Proof Ratings |
IP67 |
| Impact Protection |
IK10 |
| Dimensions |
Φ 5.6″ × 3.9″ (Φ 141 × 99.6 mm) |
| Weight |
1.8lb. (820 g) |
|
