LTS CMIP75122NF-SE 12MP IR Outdoor Fisheye IP Security Camera with Built-in Microphone, Speaker
CMIP75122NF-SE is a fisheye network camera capable of providing a 360-degree panoramic image of its surveillance scene. The progressive scan CMOS sensor provides high-resolution images of up to 4000 ? 3000. Up to 18 live view display modes, designed for 3 mount types, meet various user preference. Three independently controlled IR lights offer a range of 50ft and provide good vision in low or even zero-light environment.
LTS CMIP75122NF-SE 12MP IR Outdoor Fisheye IP Security Camera with Built-in Microphone, Speaker
Features:
- 12MP
- 2 mm Fixed Lens
- Horizontal FOV 180? (wall mount), 360?(ceiling mount), 360?(table mount)
- H.265+/H.265/H.264+/H.264
- 1/1.7″ Progressive Scan CMOS
- Max. 4000 x 3000 @20fps
- Up to 18 live view display modes
- Digital WDR
- Up to 50ft(15m) IR range
- Support microSD/SDHC/SDXC card (256 G)
- Built-in microphone and speaker
- Smart features 6 behavior analyses, and 3 exception detections
- Weatherproof IP67,
- Vandal Proof IK10
- ONVIF (PROFILE S, PROFILE G), ISAPI
| Brand | |
|---|---|
| Resolution | |
| Warranty | |
| Compression | |
| Field Of View (Horizontal) | |
| Lens Type | |
| Lens Size | |
| Technology | |
| Night Vision Range (ft) |
Specifications
| Camera | |
| Image Sensor | 1/1.7” Progressive Scan CMOS |
|
Min. Illumination |
Color: 0.082 Lux @ (F2.8, AGC ON),
B/W: 0.016 Lux @ (F2.8, AGC ON), 0 Lux with IR |
| Shutter Speed | 1 s to 1/100,000 s |
| Slow Shutter | Yes |
| Day & Night | IR Cut Filter |
| Digital Noise Reduction | 3D DNR |
| WDR | Digital WDR |
| Lens | |
| Focal Length | 2 mm |
| Aperture | F2.8 |
| FOV | Horizontal FOV 180° (wall mount), 360°(ceiling mount), 360°(table mount) |
| Lens Mount | M12 |
| IR | |
| IR Range | Up to 50ft(15 m) IR range, 3 LEDs. Each LED is independently controlled. |
| Wavelength | 850 nm |
| Compression Standard | |
|
Video Compression |
Main stream: H.265+/H.265/H.264+/H.264 Sub stream: H.265/H.264/MJPEG |
| H.264 Type | Baseline Profile/ Main Profile /High Profile |
| H.264+ | Main stream supports |
| H.265 Type | Main Profile |
| H.265+ | Main stream supports |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| SVC | H.265 and H.264 support |
| Smart Feature-set | |
| Behavior Analysis | Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection |
| Exception Detection | Audio exception detection |
| Region of Interest | 4 fixed regions for main stream and sub-stream |
| Image | |
| Max. Resolution | 4000 × 3000 |
| Main Stream Max. Frame Rate | 50Hz: 20fps (4000 × 3000), 25fps (3000 × 3000, 2560 × 2560)
60Hz: 20fps (4000 × 3000), 30fps (3000 × 3000, 2560 × 2560) |
| Sub Stream
Max. Frame Rate |
50Hz: 20fps (720 × 720, 640 × 480)
60Hz: 20fps (720 × 720, 640 × 480) |
| Image Enhancement | BLC, HLC, defog, 3D DNR |
| Image Setting | Saturation, brightness, contrast, sharpness, AGC and white balance are adjustable by client software or web browser |
| Day/Night Switch | Day/Night/Auto/Schedule/Triggered by Alarm In |
| Picture Overlay | LOGO picture can be overlaid on video with 128 × 128 24bit bmp format |
| Live View Display | |
| Mount Type | Support table, wall, and ceiling mounting |
