Camera |
Image Sensor |
1/3″ Progressive Scan CMOS |
Effective Pixel |
2560(H) ×1440(V) |
Min. Illumination |
Color: 0.005 Lux @(F1.6, AGC ON) B/W: 0.001 Lux @(F1.6, AGC ON) 0 Lux with IR |
White Balance |
Auto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp |
AGC |
Auto / Manual |
WDR |
120dB |
Digital Noise Reduction |
3D DNR |
Backlight compensation |
BLC |
Shutter Speed |
1 ~ 1/30,000s |
Day & Night |
IR Cut Filter |
Digital zoom |
16X |
Focus Mode |
Auto / Semiautomatic / Manual |
Privacy Mask |
24 programmable privacy masks |
Lens |
Focal Length |
2.8 mm to 12 mm, 4× optical |
Zoom Speed |
Approx. 2 s (optical lens, wide-tele) |
Angle of View |
Horizontal field of view: 100° to 33° (Wide-Tele)
Vertical field of view: 53° to 18° (Wide-Tele)
Diagonal field of view: 119° to 37.5° (Wide-Tele) |
Min. Working Distance |
10 ~1500mm (Wide-Tele) |
Aperture Range |
F1.6 ~ F2.7 |
Pan and Tilt |
Pan / Tilt Range |
Pan: 0° to 330°; Tilt: 0° ~ 90° |
Pan / Tilt Speed |
Pan manual speed: 0.1° ~ 100°/s, Pan preset speed: 100°/s
Tilt manual speed: 0.1° ~ 100°/s, Tilt preset speed: 100°/s |
Proportional Zoom |
Support |
Number of Preset |
300 |
Power-off Memory |
Support |
Local Video and Audio |
Network Interface |
1 RJ45 10 M/100 M Ethernet, PoE |
Audio input / putput |
1-ch audio input and 1-ch audio output |
Network |
Max. Image Resolution |
2560×1440 |
Frame Rate |
50Hz: 25fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 24fps (2560 × 1440), 30fps (2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720) |
Image Compression |
Main Stream: H.265+/H.265/H.264+/H.264 |
ROI encoding |
Main stream, sub-stream, and third stream respectively support two fixed areas. |
SVC |
Support |
Audio Compression |
G.711alaw/G.711ulaw/G.722/G.726/MP2L2/PCM |
Protocols |
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE |
Simultaneous Live View |
Up to 20 |
API |
Open-ended, support ONVIF, ISAPI, and CGI, support Third-Party Management Platform |
SD Memory Card |
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR |
User/Host Level |
Up to 32 users, 3 levels: Administrator, Operator and Use |
Security Measures |
User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering |
IR |
IR Distance |
Up to 66ft(20 m) |
Smart IR |
Support |
General |
Working Temperature
/Humidity |
-4°F ~140°F (-20°C ~ 60°C)
90% or less |
Power Supply |
12 VDC & PoE, Max.: 12 W (Max. 3.9 W for IR) |
Protection Level |
IP66 Standard;
TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection |
Dimension |
Φ 5.15″ × 4.00″(Φ 130.7 mm × 101.7 mm ) |
Weight |
Approx. 1.17Ibs (0.53Kg) |
