| Specifications |
|
Camera |
| Image Sensor |
1/2.8″ Progressive Scan CMOS |
|
Min. Illumination |
Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with white light Color: 0.0068 Lux @ (F1.4, AGC ON), 0 Lux with white light |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Slow Shutter |
Yes |
| Day & Night |
IR Cut Filter |
| Digital Noise Reduction |
3D DNR |
| WDR |
120dB |
| 3-Axis Adjustment |
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Lens |
| Focal length |
6 to 22mm |
| Lens Type |
Motorized |
| Aperture |
F1.6 |
| Focus |
Auto |
|
FOV |
Horizontal field of view: 42.4° to 17.4°
Vertical field of view: 23.4° to 9.2° Diagonal field of view: 49.6° to 20° |
| Lens Mount |
Φ14 |
| Compression Standard |
|
|
Video Compression |
Main stream: H.265/H.264
Sub stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
| H.264 Type |
Main Profile/High Profile |
| H.264+ |
Main stream supports |
| H.265 Type |
Main Profile |
| H.265+ |
Main stream supports |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| Smart Feature-set |
|
|
Behavior Analysis |
Line crossing detection, intrusion detection, unattended baggage detection, object removal detection |
| Exception Detection |
Scene change detection |
| Face Detection |
Yes |
| Region of Interest |
Support 1 fixed region for main stream and sub-stream |
| Image |
| Max. Resolution |
1920 × 1080 |
|
Main Stream |
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
|
Sub Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
|
Third Stream |
50Hz: 25fps (1920 × 1080, 1280×720, 640 × 360, 352 × 288)
60Hz: 30fps (1920 × 1080, 1280×720, 640 × 360, 352 × 240) |
| Image Enhancement |
BLC/3D DNR/HLC |
| Image Setting |
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance adjustable by client software or web browser |
|
