| Camera |
| Image Sensor |
2 MP CMOS |
| Signal System |
PAL/NTSC |
| Resolution |
1920 (H) × 1080 (V) |
| Frame Rate |
PAL: 1080p@25fps
NTSC: 1080p@30fps |
| Min. Illumination |
Color: 0.003 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Time |
PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s |
| Slow Shutter |
MAX. 16 times |
| Lens |
2.7 mm to 13.5 mm motorized, auto focus |
| Horizontal Field of View |
103° to 32.1° |
| Lens Mount |
Φ14 |
| Day & Night |
ICR |
| WDR (Wide Dynamic Range) |
≥ 130 dB |
| Angle Adjustment |
Pan: 0° to 355°, Tilt: 0° to 75°, Rotate: 0° to 355° |
| Menu |
| Image Mode |
STD/HIGH-SAT |
| AGC |
Yes |
| Day/Night Mode |
Auto/Color/BW (Black and White) |
| White Balance |
Auto/Manual |
| AE (Auto Exposure) Mode |
WDR/BLC/HLC/Global |
| Privacy Mask |
4 programmable privacy masks |
| Motion Detection |
4 programmable motion areas |
| NR (Noise Reduction) |
3D DNR/2D DNR |
| Language |
English |
| Functions |
Brightness, Sharpness, Mirror, Smart IR |
| Interface |
| Video Output |
Switchable TVI/AHD/CVI/CVBS |
| General |
| Operating Conditions |
-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensing) |
|
Power Supply |
12 VDC ±25%, 24 VAC±25%
*You are recommended to use one power adapter to supply the power for one camera. |
| Power Consumption |
Max. 7.5W |
| Protection Level |
IK10, IP67 |
| Material |
Metal |
| IR Range |
Up to 197ft(60 m) |
| Dimensions |
Φ 145.2 mm × 124.1 mm ( Φ 7.1″ × 4.9″) |
| Weight |
Approx. 640 g (1.41 lb.) |
